METROPOLITAN LOW VOLTAGE PADDLE KEYPAD V2 (BLACK)

WIB-BKLV02V2-00

Registrate para ver precios

The Savant Metropolitan Low Voltage Paddle Keypad offers intuitive, two button control. Buttons can be configured to act as a traditional on/off device or can be programmed to activate more complex scenes including lighting, shades, climate, AV and other services. New Roaming Assisted Discovery (RAD) allows multiple keypads to be provisioned to the local network. Simply provision one keypad, enable RAD, then join the other keypads to the network with the push of a button. Faceplates sold separately.

KEY FEATURES

  • Ambient Light Sensor - Detects the level of ambient light in the room and adjusts the LED brightness on the front panel
  • Fits standard decorator-style wall plates
  • Nine LED Color Options
  • Simple to configure and deploy using Blueprint Lighting Manager

DOCUMENTS

  • Echo and Metropolitan Style Low Voltage Keypads (V2) - QRG View

WARRANTY

Basic warranty period is five (5) years excluding misuse defined as abuse, accidental damage, modifications, improper wiring, improper repair, incorrect repair, and operation outside specified operating temperatures and humidity. For further warranty information on this product please refer to the Savant New Product Limited Warranty document.

Learn more

SPECS

Environmental

  • Temperature - 32° to 104° F (0° to 40°C)
  • Humidity - 10% to 90% (non-condensing)

Dimensions and Weights

  • Height - 4.13 in (10.50 cm)
  • Width - 1.72 in (4.36 cm)
  • Depth - 0.97 in (2.46 cm)
  • Weight - Shipping: 0.6 lbs (0.27 kg)

Power

  • Input - 24V DC 2A
  • Avg Power - 0.5 Watts
  • Max Power - 1.4 Watts

Minimum Support Requirements: da Vinci 10.4

NOTE: Not supported as a BLE Gateway.

Información adicional

Peso0.27 kg
Dimensiones10.50 × 4.36 × 2.46 cm
