Environmental

Temperature: -4° to 122° F (-20° to 50° C)
Humidity: Up to 90% Relative Humidity (non-condensing)
Location: Indoor use unless installed in an IP65 rated plastic enclosure

Dimensions and Weights

Device (D x W x H): 1.6 in x 7.5 in x 4.3 in (4.1 cm x 19.1 cm x 10.9 cm)
Device Weight: 1.5 lbs (.68 kg)
Shipping (D x W x H): 3.0 in x 9.0 in x 9.0 in (7.6 cm x 22.9 cm x 22.9 cm)
Shipping Weight: 3.1 lbs (1.41 kg)

Power

Power Supply: 120 V AC to 5V DC (3A) external supply
Maximum Power: 15 W
Power over Ethernet: IEEE 802.3af

Standards

Bluetooth: Bluetooth Low Energy 5.1 (BLE)
Wi-Fi: 2.4/5.0 GHz IEEE 802.11 a/b/g/n/ac
Ethernet: IEEE 802.3af

Regulatory

Safety and Emissions: FCC Part 15
FCC ID: ASU-DIRECTOR
IC: 10052A-DIRECTOR
Contains FCC ID: VPYLB1ZM
Contains IC: 772C-LB1ZM
RoHS: Compliant

Box Contents

(1) Director
(1) 5V DC (15 W) power supply
(2) 3-pin screw down connector
(3) 2.4-5 GHz dual band antenna
(1) Side mount chassis bracket
(2) M3 x 6mm flat head screws
(1) Product Regulatory Statement

Accessories (Sold Separately)

SEM-VT01 SmartEnergy Voltage Sensor
SEM-150A1 Smart Energy Sensor - 150 Amp
SEM-250A1 Smart Energy Sensor - 250 Amp
SEM-2015 Stand Alone Energy Monitor

Minimum Supported Release

da Vinci 10.2
